，Dimensions
(Unless otherwise specified,a tolerance of ＼0.4mm a pplies to all dimensions)


Wide selection of two-circuit double-break limit switches
，Features
.Rifid diecast switch housing
.Set position indicator plate for easy maintenance
.High mechanical strength
.Oiltight,waterproof and dustproof construction
，Specifications
.Ratings
Rated
voltage
(V)
Non-inductive load(A)
Inductive load(A)
Resistive
load
Lamp
load
Inductive
load
Motor load
N.C.
N.O.
N.C.
N.O.
N.C.
N.O.
N.C.
N.O.
125　VAC
250　VAC
480　VAC
600　VAC
10
5
3
1
10
5
3
1
3
2
1.5
1
1.5
1
0.8
0.5
10
5
3
1.5
5
3
1.5
1
2.
1.0
0.8
0.5
8　VDC
14　VDC
30　VDC
125　VDC
250　VDC
10
10
6
0.8
0.4
6
6
4
0.2
0.1
3
3
3
0.2
0.1
10
10
6
0.8
0.4
6
6
4
0.2
0.1
Notes: 1. Inductive load: power factor = 0.4; time constant= 7msec.
　　　　2. Lamp load has an inrush current of 10 times the steady-state current while
　　　　motor load has an inrush current 6 times the steady-state current.
